NGA100SSPUL

NGA100SSPUL

100 kVA Prime Output, Single/Three-Phase

MQ Power WhisperWatt Super-Silent portable generators provide reliable power to meet the most demanding requirements. They are designed and built to withstand tough environments at construction sites and provide dependable temporary power at entertainment venues and disaster recovery operations.

The NGA100SSPUL offers a prime rating of 80 kW (100 kVA) and a standby rating of 88 kW (110 kVA). Our patented open delta generator winding provides precise voltage control, allowing superior motor starting capability. An electronic governor maintains frequency to ± 0.25% from no load to full load. Equipped with an EPA Certified PSI natural gas engine to easily meet the stringent EPA standards while providing profitable performance and reliability.

The unit features a sound attenuated, weather resistant, steel housing provides operation at 68 dB(A) at 23 feet. Fully lockable enclosure allows safe unattended operation, E-Coat primer and powder coat paint provides durability and weather protection, an auto start stop equipped controller that allows the generator to start from a remote location.





Unit Specifications
Prime Rating 80 kW 100 kVA
Standby Rating 88 kW 110 kVA
Generator RPM 1800
Voltage - Three Phase 208, 220, 240, 416, 440, 480V Switchable
Voltage - Single Phase 120, 127, 139, 240, 254, 277V Switchable
Generator Design Revolving field, Self-ventilated, Drip-proof, Single bearing
Voltage Regulation (No Load to Full Load) ±0.5 %
Power Factor 0.8
Armature Connection Star with Neutral/ Zig Zag
Excitation Brushless with AVR
No. Poles 4-pole
Frequency 60 Hz
Frequency Regulation (steady state load) ±0.25 %
Sound Level (Full Load at 23 ft.) 68 dB(A)
Engine Specifications
Make/ModelNGA100SSPUL
EmissionsEPA Certified
Starting SystemElectric
Design 4-cycle, Water Cooled, Natural Aspriated
Gross Engine Power Output - Prime Rating:
   Natural Gas146 bhp109 kW
   LP166 bhp124 kW
Gross Engine Power Output - Standby Rating:
   Natural Gas162 bhp121 kW
   LP185 bhp138 kW
Fuel Consumption (NG):
   Full load818 ft3/hr23.16 m3/hr
   3/4 load 649 ft3/hr18.38 m3/hr
   1/2 load497 ft3/hr 14.07 m3/hr
   1/4 load348 ft3/hr 9.85 m3/hr
DEF Tank CapacityN/A galN/AL
Coolant Capacity6.34 gal24 L
Oil Capacity 3.1 gal11.8 L
Battery12V 121Ah x 1
Notice: Features and equipment specifications are subject to change without notice.
