WM120PHD

WM120PHD

12cf Mortar, Hydraulic Drive/Dump, Honda GX390
Multiquip/Whiteman stands above the rest with the construction industry's most extensive variety of tried and tested plaster/mortar mixers.
  • Hydraulic drive mixes larger, lower-slump loads
  • Hydraulic dump allows high production with minimal operator fatique
  • Mixes 12 cubic feet (340 liters) of material
  • Powered by a reliable  Honda GX390 engine
  • Thick 14-gauge engine cover resists vibration
  • Power coat paint with a durable lasting finish




Unit Specifications
Drive System Hydraulic
Drum Capacity 12 cu. ft
339.8 L
3 1/2 - 4 bags
Dump Type Hydraulic
Discharge Height 17 in 430 mm
Drum Type Poly
Drum Thickness 7
Engine Cover Thickness 14
Tire Size B78x13
Frame Type Tubular
Paint Type Tubular
Power Source Honda 13 HP model GX390
Dimensions & Weights
Overall Length 82 in 2082.8 mm
Overall Width 51 in 1295.4 mm
Overall Height 60 in 1520 mm
Overall Height
w/Dump Handle
75 in 1910 mm
Operating Weight 1090 lb 494.4 kg
Engine Specifications
Engine Make/Model Honda GX-390
Start Method Recoil
Engine Power 11 HP 8.2 kW
Engine RPM 3600
Fuel Type Gasoline
Notice: Features and equipment specifications are subject to change without notice.
