MTX70HDR Rammer Honda GXR120 Diaphragm Carb



Year: 2024 | Serial #: K-12352
Price: $3713.00
List Price: $5801.00
Warranty Terms: Full Term
Machine Hours:
Location: San Bernardino CA

Condition:

Used for demo , some scratches



MTX70HDR — 4‑Cycle Tamping Rammer

Honda GXR120 Engine | 3,350 lbf Impact Force | 11.2 in. Shoe

The Multiquip Mikasa MTX70HDR is engineered for high‑performance compaction, especially in high‑altitude environments where consistent power is essential. Equipped with Honda’s purpose‑built GXR120 engine, this rammer delivers exceptional output, reliability, and fuel efficiency. The MTX‑Series is widely recognized for its durability, operator comfort, and ease of operation—making it a top choice for contractors.

Key Features

High‑Output Honda GXR120 Engine

  • Designed specifically for rammer applications

  • Reliable 3.6 HP performance

  • Optimized for high‑altitude operation

  • EPA‑compliant fuel tank reduces evaporative emissions

Contractor‑Preferred MTX‑Series Design

  • Cyclonic air cleaner captures 98% of airborne dust for longer engine life

  • Laminated wood and steel shoe for long‑lasting durability

  • Low‑vibration handles reduce operator fatigue during extended use

  • Integrated hour meter/tachometer for maintenance tracking

  • Heavy‑duty engine guards protect against jobsite impacts

Specifications

Unit Specifications

  • Blows per Minute: up to 690

  • Impact Force: 3,350 lbf (14.9 kN)

  • Shoe Jump Height: 3.1 in (79 mm)

  • Shoe Dimensions (L × W): 13.4 × 11.2 in (340 × 285 mm)

  • Travel Speed: 55.8 ft/min (17 m/min)

  • Fuel Tank Capacity: 2.7 qt (2.5 L)

Dimensions & Weight

  • Length: 31.0 in (788 mm)

  • Width: 13.8 in (350 mm)

  • Height: 40.4 in (1027 mm)

  • Operating Weight: 165 lb (75 kg)

Engine Specifications

  • Make/Model: Honda GXR120

  • Start Method: Recoil

  • Power: 3.6 HP (2.7 kW)

  • Engine RPM: 4,100

  • Fuel Type: Gasoline
